Factory-direct industrial pallet racks, heavy-duty shelving, and automated logistics equipment optimized for Philippine warehouses, logistics hubs, and cold storage facilities.
The fast-paced expansion of the Philippine logistics, FMCG, e-commerce, and cold chain sectors—driven by major infrastructure developments in Greater Metro Manila, Central Luzon, and Metro Cebu—has created unprecedented demand for resilient, high-density industrial warehouse storage systems. Industrial real estate values in key logistics corridors such as Laguna (Biñan, Santa Rosa), Cavite (General Trias, Silang), and Bulacan have escalated rapidly. Consequently, industrial warehouse operators can no longer afford inefficient floor-stacking techniques.
As a leading certified manufacturer and global exporter of industrial storage equipment, we engineer high-grade Adjustable Pallet Racks specifically suited to Philippine environmental, seismic, and economic conditions. Featuring pitch beam adjustability (50mm / 75mm), high structural yield steel components (Q235B and Q355B structural grades), and advanced anti-corrosion surface treatments, our heavy-duty racking systems maximize vertical cubic space while ensuring 100% SKU accessibility and structural integrity.
Engineered to satisfy NSCP (National Structural Code of the Philippines) parameters, utilizing custom baseplates and frame bracing built for typhoon and earthquake zones.
Complete documentation provided under the ASEAN-China Free Trade Area (ACFTA), allowing Philippine importers to claim zero percent (0%) import tariffs.
In-house electrostatic powder coating line achieving 80–100μm film thickness, preventing corrosion in humid, tropical maritime Philippine logistics environments.
Pallet rack design for Philippine deployment requires rigorous engineering considerations that exceed generic global templates. Warehouses located in seismic hazard areas (along the Marikina Valley Fault System or coastal provinces) require strict structural calculations under international specifications including FEM 10.2.02, ANSI MH16.1, and AS4084-2012.
Our heavy-duty upright frames utilize cold-rolled Omega-profile structural steel with 9-fold and 11-fold continuous cold-bent geometry. This geometric profiling increases moment of inertia and flexural torsional buckling resistance. Beams are manufactured from twin-C interlocking steel profiles or step-beam extrusions welded to heavy-gauge multi-hook beam end connectors.
| Racking Component | Material Specification | Dimension Profile Range | Yield Strength (Fy) | Philippine Application Standard |
|---|---|---|---|---|
| Upright Frames | Q235B / Q355B Cold Rolled Steel | 80×60, 90×70, 100×70, 120×95 mm | ≥ 235 MPa to ≥ 355 MPa | Seismic Zone 4 Braced (NSCP 2015) |
| Box & Step Beams | High-Tensile Interlocking C-Profile | 80×50 to 160×50 mm (1.5-2.0mm thk) | ≥ 235 MPa | Max 4,500 kg / Tier (Uniformly Distributed) |
| Wire Mesh Decking | 5.0mm Cold Drawn Steel Wire | 50×100mm mesh, 3-4 support channels | ≥ 500 MPa | NFPA 13 Fire Sprinkler Penetration Compliant |
| Galvanized Decking | Pre-Galvanized Structural Sheet | 0.7mm – 1.2mm Ribbed Panels | ≥ 275 MPa | Cold Storage (-30°C) & High Humidity Hubs |
Philippine facilities, particularly those operating near major ports (Manila South Harbor, Port of Subic, Port of Cebu, Davao Sasa Port), face high ambient relative humidity (75–90%) and airborne salinity. Standard wet painting degrades quickly under these conditions, causing hidden rust beneath the paint film.
Our manufacturing facility eliminates this risk by employing a fully automated 9-stage chemical pretreatment process: Degreasing → Water Rinse → Rust Removal → Neutralization → Water Rinse → Surface Conditioning → Phosphating → High-Pressure Clean Water Rinse → Deionized Water Wash. Components are subsequently coated with non-toxic, lead-free pure epoxy-polyester powder and cured at 200°C for 20 minutes, passing the strict ASTM B117 salt spray test for over 500 hours.
Understanding the unique operational layout of different regional industrial corridors in the Philippines enables precise selection of adjustable pallet rack configurations:
As an established manufacturer with over two decades of international export experience, we bridge the gap between factory-direct pricing and high-end structural safety engineering. Overseas procurement managers choose us because we eliminate the middlemen and guarantee direct engineering support from initial CAD layout design to final container loading.
Our structural engineers provide free 2D warehouse layout designs and 3D rendering calculations tailored to your forklift turning radius and building clear heights.
Equipped with state-of-the-art continuous roll-forming lines, robotic laser cutters, and automatic welding arms ensuring ±0.5mm tolerance across all uprights and beams.
Racking orders are flat-packed with protective film and wooden skids, engineered to maximize 40ft HC container weight/cube limits to keep ocean freight costs per pallet position low.
Direct technical answers to common queries raised by Philippine logistics directors, warehouse owners, and customs brokers:
Need a custom CAD racking layout, weight load consultation, or instant FOB/CIF Manila port price quote? Contact our senior engineering team now for factory-direct guidance.
